Laser Heads

IMA TECNO Laser heads can be the basis for applications on machines in which the laser unit, as envisaged by the Customer, can be mounted to have 5-axis solutions both vertically and horizontally.

DOWNLOAD CATALOG

Taylor Made
Laser Head Horizontal

Laser Head Horizontal

  • Rotation Axes 45
    Working rotation axes
  • Hposition
    Horizontal Position
Laser Head Vertical

Laser Head Vertical

  • Rotation Axes 45
    Working rotation axes
  • Vposition
    Horizontal Position
Laser Head Direct Drive

Laser Head Direct Drive

  • Rotation Axes 45
    Working rotation axes
  • Vposition
    Horizontal Position

Main Info for Laser Heads

Laser Heads add A and B axis rotation to standard 3-axis machines.
The heads can be installed both vertically and horizontally.
The strength of our heads is the possibility of using a wide range of servo motors chosen by the customer (Bosch, Delta, Mitsubishi, Siemens, Fanuc, Kollmorgen; Beckhoff, Yashkawa, Heidenhain, Lenze, Panasonic, Hiwin and others. ).

The Z axis slide can have, optionally, a stroke from 250 to 500 mm. The slide, designed for easy assembly in the machine, is made in a sturdy way and protected with metal bellows. It is also equipped with zeroing and limit switch sensors.
